USE WITH OTHER MIDI FOOT CONTROLLERS
You can use Control Switcher with any MIDI controller capable of sending program change (PC) or control change (CC) messages. Following the instructions below in the SETUP section of this manual, you will set Control Switcher to respond to either PC, CC or both message types, as well as which MIDI channel. If you are using CC, you also need to specify which group of CC numbers.
Once setup, you can save and then recall preset combinations of switch settings by sending a PC message from your MIDI foot controller. Here’s how:
1.) Send the PC message from your foot controller for the preset you want to create.
2.) Set the Control Switcher switches to the desired combination.
3.) Press and hold button #1. At the same time, press button #4. The LEDs will blink to confirm that you saved the preset.
Now whenever Control Switcher receives this PC message, it will recall your switch settings.
Note: You must configure Control Switcher to respond to MIDI program change messages. To do this, go to the following sections of this manual:
SETUP: MIDI Program Change and Control Change Enable SETUP: Set MIDI Channel
To use MIDI control change messages for Instant Access buttons, go here as well:
SETUP: Select Control Change Numbers
